SKKL-F

■Product features
The SKKL-F model is a swing-arm product that can be clamped to a desk.
The newly designed, LED-exclusive slim head uses a board-mounted LED with high color rendering (Ra≧90) and heat generation.
A flat, diffuser and protector will reduce the work and the light source as well as the glare unique to LEDs.
The on/off switch is on the head for better control.
The newly designed clamp attachment takes reinforcement and work efficiency into account, taking up less space, staying out of your way.
The head swings horizontally, allowing more range and freedom of the arm and the clamping position.

■Product Name
LED Illuminated Magnifier

■Model
SKKL-F (Free-arm illuminated magnifier)

■Product Specifications

Lens
Magnifier Lens Magnification Lineup 2x, 3x, 4x, 6x, 8x, 10x, 12x, 15x
AR (anti-reflection) Coated Lens Lineup Available / 2x, 3x, 4x, 6x, 8x, 10x
Lighting
Light source High Color Quality White LED(CRI≧90) with Protective cover for diffusion
Input voltage 100～240V: 50/60 Hz: Plug Type A
*Change or purchase an additional AC cord to use at 125-240V.
Please contact your sales dealer for details.
Power consumption 7W
Dimming Function Not available
Body
Weight (Kg) 2.0kg (Without lens and AC adapter/body weight)
Possible clamping width (mm) 15〜60
AC Adapter dimension : 96×44×H29[mm] (Not include wires)
Weight : 0.3kg(Include wires)
Operating temperature range 5℃～35℃
Dustproof and waterproof protection grade IP20 (indoor use only)
